ATS US-2100 TTP Banding Machine
Part Number: US-2100-TTP-430-205-100
Wide Band Banding machine and thermal printer in one - eliminate the need for additional labeling/marking
 | Print image up to 128mm length |
| | 75mm & 100mm band width versions |
| | Max product size: 16" width x 7.25" height |
Feel free to give us a call or reach out to our contact form with this part number for pricing and questions.
-
Contact us for pricing
- Band Width : 100mm
- Max Product Size (mm) W x H : 410 x 185mm
- Max Product Size (in) W x H : 16 x 7.25 in.
- Seal Type : Ultra-Sonic
- Availability: Available to Order
The automatic banding machine, equipped with a thermal transfer printer, directly prints product information onto the band. The US-2100 TTP imprints essential details like the company logo, packaging and expiry dates, EAN code, and price onto the paper or foil band before securing it around the product. With its adjustable printer position, the information remains precisely placed, even when accommodating different product sizes.
Features
• Banding and labeling in one step, short changeover time
• Adjustable printhead for optimal positioning of band printing
• Robust ultra-sonic welding technology
• Digital operator interface
• Limitless options for materials
•Ideal for data, item numbers, bar codes, company logos, short descriptions, etc.
Specifications
| Technical Data | |
| Model: | US-2100 TTP |
| Max Product Width: | 410mm (16.14 in) |
| Max Product Height: | 185mm (7.28 in.) |
| Print Image Length: | Up to 128mm (5.04 in.) |
| Machine Height: | 1490mm (58.66 in.) |
| Machine Width: | 1515mm (59.65 in.) |
| Machine Depth: | 685mm (26.97 in.) |
| Weight: | 270kg (595 lbs) |
| Air Supply: | 6 bar (87 psi) |
Documents
 |
| Ultra-Sonic Catalog |
Videos
