Meech 261v2 DC Ionising Nozzle w/ 1/4" BSP Inlet & Flexible Outlet
Part Number: 261V2-32-FLEX-1/4
The Meech Model 261v2 Flexi Nozzle is a compact ionizer featuring a 1/4" BSP inlet and an outlet extended with flexible knuckle trunking.
This nozzle is tailored for use with a Meech Pulsed DC Controller and can be easily integrated into machinery and equipment. Simply connect compressed air on the inlet end, and ionized air will be discharged from the outlet nozzle It excels in high-speed applications, particularly in sheet delivery systems.
Meech Pulsed DC Controller Sold Separately
List price: $305.00 /EACH
- Availability: Available to Order
Complete System:
- 261v2 Ionizing Nozzle (up to 2 per power supply)
- 233V4 Power Supply (x1)
- 900IPS Power Cable (x1)
Optional:
- Splitter (run more than 2 ionizing nozzles off 1 power supply, up to 14+ with additional splitters)
Specifications
| Technical Information | |
| Air Fitting (Inlet): | 1/4" BSP |
| Air Fitting (Outlet): | Flexible trunking nozzle |
| Mas Air Pressure: | 100 psi (7 bar) |
| Typical Pressure: | 20 to 40 psi (1.5 to 3 bar) |
| Emitter Pins: | Machined Titanium (replaceable) |
| Decay Time: | 0.8 sec at 150mm at 30 psi |
| Ozone: | less than 0.1 ppm |
| Input Voltage: | +/- 9kV DC Nominal |
| Ion Balance: | +/- 10V or better at set up |
Documents
 |  |
| Data Sheet | Operating Manual |
Accessories
Power Supply: 233V4
Mounting Bracket: 260FIX
Splitter: 4WAY
Static Locator: 983V2
Other Nozzle Options
261V2-32-FLEX: 6mm Push-fit Inlet & Flexible Outlet
261V2-32-1/4OUT: 6mm Push-fit Inlet & 1/4" BSP Outlet
261V2-32-BSP: 1/4" BSP Inlet & 1/4" BSP Outlet
