Post Stitcher, 7/16 Cr, 16 inch Throat, (.103X.020 Wire) 115VAC/60Hz
Double-tap and hold to zoom.
Mouse over the image to zoom.

Post Stitcher, 7/16 Cr, 16 inch Throat, (.103X.020 Wire) 115VAC/60Hz

Part Number: HF16P-AST

Use a post-type stitcher to assemble various styles of slotted boxes, including regular, overlap, full overlap, and half-slotted boxes with partial covers. These stitchers effectively and securely close the bottoms of boxes. Choose a model based on your production needs and the size of stitches required.

For assembling up to 3,000 boxes per day, opt for a regular-duty Silverstitcher. These machines are easy to use, robust, and deliver consistent performance throughout the day.

For more demanding tasks, such as stitching together multiple layers of corrugated cardboard or assembling solid fibreboard boxes, choose the ISP S5 Heavy Duty Stitcher.

$6,290.00 /EACH
List price: $6,290.00 /EACH
    • EACH
  • Availability: Available to Order

Specifications:

Technical Characteristics
Distance from Front of Frame to Clincher: 16" (41cm)
Height from Base Top to Clincher: 41.5" (105cm)
Maximum Box Width: 32" (81cm)
Maximum Box Depth: 41.25" (105cm)
Crown Size:  7/16" (11mm)
Wire Sizes: .103x.014 / .103 x .017 / .103 x .020
Wire Coil Capacity: 25 lb. (11kg)
Stitches Per Minute: 250
Motor:
1/3 HP, 1725 RPM, 115V/60Hz/AC, Single Phase
Dimensions (W x D x H): 40" x 48" x 78" (102 x 122 x 198cm)
Shipping Weight: 515 lbs. (247kg)

Documents:


HF Stitcher Manual
